Spektrum:
Channel Spacing Configurable on 5 MHz increments
Frequency Range 4910–5980 MHz (exact frequencies as allowed by local regulations)
Channel Width 10 | 20 | 40 | 80 MHz (NOTE: 10 MHz bandwidth is supported only with Force 300-19R SM. Also note that 11n SM's can connect and operate in 10MHz)
Interfész:
MAC (Media Access Control) Layer Cambium Proprietary
Physical Layer 4x4 MUMIMO/OFDM
Ethernet Interfaced 100/1000BaseT, rate auto negotiated, 802.3at compliant & Aux SFP port
Powering Methods Supported 56 V PoE (included), standard 802.3at PoE Supply, or CMM5 with 56 V and 5 pin to 7 pin cross over cable adapter
Protocols Used IPv4/IPV6 , UDP, TCP, IP, ICMP, SNMPv2c, HTTPs, STP, SSH, IGMP Snooping
Network Management HTTPs, SNMPv2c, SSH
VLAN 802.1Q with 802.1p priority
Teljesítmény:
Subscribers per Sector Up to 120
ARQ Yes
Nominal Receive Sensitivity (w/FEC) @20 MHz Channel MCS 0 , -92 MCS 8 supported by Wi-Fi -68
Nominal Receive Sensitivity (w/FEC) @40 MHz Channel MCS0, -89 MCS9, -64
Nominal Receive Sensitivity (w/FEC) @80 MHz Channel MCS0, -86, MCS9 - 61
Modulation Levels (Adaptive) MCS0 (BPSK) to MCS 9 (256 QAM 5/6)
GPS Synchronization Yes, via Internal GPS or Cambium Sync (Internal GPS receiver also contains a patch antenna and can be used without the external puck antenna)
Quality of Service Three level priority (Voice, High, Low) with packet classification by DSCP, COS, VLAN ID, IP & MAC Address, Broadcast, Multicast and Station Priority, MIR/CIR support*
DSO* Dynamic Spectrum Optimization. Ability to change channels based on interference detection on current channel
Fast DFS* Change to alternate radar free channel with background availability check
