Spektrum:
Channel Spacing Configurable on 5 MHz increments
Frequency range 5 GHz: 4910 – 5970 MHz (exact frequencies as allowed by local regulations)
Channel Width 5 | 10 | 20 | 40 MHz
Interfész:
MAC (Media Access Control) Layer Cambium Proprietary
Physical Layer 2x2 MIMO/OFDM
Ethernet Interface 100/1000BaseT, rate auto negotiated (802.3af compliant)
Powering Methods Supported 30V PoE Supply (included), CMM3 & CMM4, 802.3af PoE Supply
Protocols Used IPv4/IPv6 (Dual Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH
Network Management IPv4/IPv6, HTTPs, SNMPv2c, SSH, Cambium Networks CnMaestro™
VLAN 802.1Q with 802.1p priority
Teljesítmény:
Subscribers per SectorUp to 120
ARQ Yes
Nominal Receive sSnsitivity (w/FEC) @ 20MHz ChannelMCS0 = -93 dBm to MCS15 = -69 dBm (per branch)
Nominal Receive Sensitivity (w/FEC) @ 40MHz ChannelMCS0 = -90 dBm to MCS15 = -66 dBm (per branch)
Modulation Levels (Adaptive) MCS0 (BPSK) to MCS15 (64QAM 5/6)
Latency Up to 20ms
GPS Synchronization Yes, via Internal GPS, CMM3, or CMM4
Quality of Service Three level priority (Voice, High, Low) with packet classification by DSCP, COS, VLAN ID, IP & MAC Addr, Broadcast, Multicast and Station Priority
Antenna Sector Antennas available
Transmit Power Range -17 to +30 dBm (combined, to regional EIRP limit) (1 dB interval)
Fizikai jellemzők:
Antenna Connection 50 ohm, RP (Reverse Polarity) SMA
Surge Suppression Joule Integrated
Environmental IP55
Temperature -30°C to +60°C (-22°F to +140°F)
Weight 5.1 kg (10 lbs) with antenna 0.52 kg (1.1 lbs) without antenna
Wind Survival145 km/hour (90 mi/hour) with antenna
Dimensions (h x w x d)Radio: 26.9 x 11 x 7.7 cm (10.6 x 4.3 x 3.0 in) Antenna (incl brackets): 80cm x 22.5cm x 24cm (31.5 x 8.9 x 9.4 in)
Power Consumption (over 100m CAT5 cable)10 W Maximum, 7.5 W Typical
Input Voltage 23 to 56 V
Biztonság:
Encryption 128-bit AES (CCMP mode)
