Spektrum:
Channel Spacing Configurable on 5 MHz increments
Frequency range 5 GHz: 4910 – 5970 MHz (exact frequencies as allowed by local regulations) 2.4 GHz: 2402 – 2472 MHz
Channel Width 5 | 10 | 20 | 40 MHz
Interfész:
MAC (Media Access Control) Layer Cambium Proprietary
Physical Layer 2x2 MIMO/OFDM
Ethernet Interface 100 BaseT, Cambium PoE (V+ = pins 7 & 8, Return = pins 4 & 5)
Protocols Used IPv4/IPv6 (Dual Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH
Network Management IPv4/IPv6, HTTPs, SNMPv2c, SSH, Cambium Networks CnMaestro™
VLAN802.1Q with 802.1p priority
Teljesítmény:
ARQ Yes
Nominal Receive Sensitivity (w/FEC) @ 20MHz ChannelMCS0 = -93 dBm to MCS15 = -69 dBm (per branch)
Nominal Receive Sensitivity (w/FEC) @ 40MHz ChanneMCS0 = -90 dBm to MCS15 = -66 dBm (per branch)
Modulation Levels (Adaptive) MCS0 (BPSK) to MCS15 (64QAM 5/6)
Quality of Service Three level priority (Voice, High, Low) with packet classification by DSCP, COS, VLAN ID, IP & MAC Addr, Broadcast, Multicast and Station Priority
Transmit Power Range-17 to +30 dBm (combined, to regional EIRP limit) (1 dB interval)
Fizikai jellemzők:
Antenna Connection 50 ohm, RP (Reverse Polarity) SMA (2)
Surge Suppression 1 Joule Integrated
Environmental IP55
Temperature -30°C to +60°C (-22°F to +140°F)
Weight 0.49 kg (1.1 lb.)
Wind Survival 145 km/hour (90 mi/hour) when mounted on ePMP Sector Antennas
Dimensions (h x w x d) 29.1 x 14.5 x 8.3 cm (11.4 x 5.7 x 3.3 in)
Power Consumption 7 W Maximum, 5 W Typical
Input Voltage 10 to 30 V
